PRODUCT
产品详情
| 链号 | Pitch (mm) 节距 (mm) | Pin diameter (mm) 销轴直径 | Bush diameter (mm) 套筒直径 | Sibebar thickness (mm) 链板厚度 | Sibebar width (mm) 链板宽度 | Ultimate Strength Minimums (N) 最小拉伸载荷 |
| WHX132 | 153.67 | 25.40 | 44.45 | 12.70 | 50.80 | 378000 |
| WHX132 | 153.67 | 25.40 | 44.45 | 12.70 | 50.80 | 378000 |
| WHX124 | 101.60 | 19.05 | 36.58 | 9.53 | 38.10 | 224000 |
| WHX124 | 101.60 | 19.05 | 36.58 | 9.53 | 38.10 | 224000 |
| WHX150 | 153.67 | 25.40 | 44.45 | 12.70 | 63.50 | 408000 |
| WHX155 | 153.67 | 28.70 | 44.45 | 14.27 | 63.50 | 463000 |
| WH78 | 66.27 | 12.70 | 22.23 | 6.35 | 28.70 | 107000 |
| WH78 | 66.27 | 12.70 | 22.23 | 6.35 | 28.70 | 107000 |
| WHX157 | 153.67 | 28.70 | 44.45 | 15.88 | 63.50 | 531000 |
| WH82 | 78.18 | 14.27 | 26.97 | 6.35 | 31.75 | 131000 |
| WH82 | 78.18 | 14.27 | 26.97 | 6.35 | 31.75 | 131000 |
| WHX124HD | 101.60 | 22.35 | 41.28 | 12.70 | 50.80 | 355000 |
| WHX106 | 152.40 | 19.05 | 36.58 | 9.53 | 38.10 | 224000 |
