产品详情
| 链号 Chain NO. | GB链号 Chain NO. | 节距 Pitch p mm | 滚子直径 Roller Diameter d1(max) mm | 内链节内宽 Inner width of inner link b1(min) mm | 销轴直径 Pin diameter d2(max) mm | 链板高度 Plate height h2 mm | 排距 Array pitch pt mm | 销轴长度 Pin length b2 mm | 止锁销附加宽度 b3 mm | 拉伸载荷 Tensile load min KN | 每米重量 Weight/m |
| 32B-1 | 32B-1 | 50.80 | 29.21 | 30.99 | 17.81 | 42.29 | - | 67.40 | 7.9 | 250.00 | 10.50 |
| 40B-1 | 40B-1 | 63.50 | 39.37 | 38.10 | 22.89 | 52.96 | - | 82.60 | 10.2 | 355.00 | 17.00 |
| 48B-1 | 48B-1 | 76.20 | 48.26 | 45.72 | 29.24 | 63.88 | - | 99.10 | 10.5 | 560.00 | 26.00 |
| 56B-1 | 56B-1 | 88.90 | 53.98 | 53.34 | 34.32 | 77.85 | - | 114.60 | 11.7 | 850.00 | 36.00 |
| 64B-1 | 64B-1 | 101.60 | 63.50 | 60.96 | 39.40 | 90.17 | - | 130.90 | 13.0 | 1120.00 | 48.00 |
| 72B-1 | 72B-1 | 114.30 | 72.39 | 68.58 | 44.48 | 103.63 | - | 147.40 | 14.3 | 1400.00 | 63.00 |
